Flat Bed Semi trailer
Dimensions: The platform length is approximately 7100-12500 millimeters, the width is approximately 2480-2500 millimeters, and the total height is approximately 1500-1550 millimeters.
Weight: Self weight of about 3.6-7 tons, load capacity between 20-50 tons
Tire specifications: 11.00R20, 12.00R20, 12R22.5, 385/65R22.5, etc., paired with corresponding steel wheel rims
Two axle flatbed truck is a common transport vehicle named after its two axles, mainly used for transporting large, heavy goods and containers. Here is its product introduction:
structural characteristics
Frame: It usually adopts a welded steel frame structure, and some models will be reinforced to withstand concentrated loads. The frame of a certain two axle flatbed truck can withstand a concentrated load of 14 tons within a range of 3 meters at the center of gravity.
Axle: Generally, well-known brands of axles such as BPW, SAF, FUWA, etc. are selected, which have good load-bearing capacity and stability, with a single axle load of up to 9 tons or more.
Suspension system: Common types include mechanical suspension, air suspension, and hydraulic suspension. Air suspension and hydraulic suspension have good shock absorption performance, and can automatically adjust the vehicle height according to road conditions and load changes, improving the smoothness of driving.
Braking system: Many braking systems that comply with relevant standards are used, such as two-line braking, EBS electronic braking system, etc., equipped with brake valves and chambers from brands such as WABCO. Some models are also equipped with ABS anti lock braking system to ensure braking effect and driving safety.
