SANY STC2000C8 Truck Crane

8-section 85.5m oval shaped boom and fixed jib 18m are standard, and the optional jib can be added up to 34m, delivering strong performance in lifting height, radius and weight. Dual engine system, DF Cummins stage III for superstructure, BENZ stage III for chassis. The fuel consumption of operation is reduced by 30% compared with hydraulic single engine system. 70t full counterweight. 18t counterweight can be carried on board when traveling from jobsite. Chassis BENZ OM460LA.E3A engine / ZF transmission / Zhuzhou Gear Transfer case / Hande axles (disc brake). 5-axle all-terrain carrier, H-type outriggers, hydro-pneumatic suspension, all-wheel steering, 6 steering modes, minimum steering radius of 10m. Independent hydraulic systems for crane and chassis (independent hydraulic system for crane operation consisting of variable piston pump + slewing pump + auxiliary pump + fluid tank), better maneuverability. Cable wiring for superstructure, IP67, easy maintenance with high reliability.

Multi-function seat with air suspension, making driving more comfortable.  Double seats and foldable berth for the co-driver.   10.1-inch touch screen integrated with back-up image and multi-media.   Electric rearview mirror with electric heating, ensuring good field of view in foul weather.   Adjustable high-brightness LED headlamps/fog lamps, providing clear vision at night.   Full-automatic HVAC, able to automatically adjust indoor temperature as demanded.

Main functions Outrigger control - outrigger beam and jack telescoping simultaneously or independently, one-key leveling. Suspension control – suspension locking / unlocking, rising / lowering, unilateral motion for auto leveling. Superstructure power-on – remote control of power on and off. Remote ignition and stalling – superstructure / chassis engine start and stop. One-key light switching – superstructure light switching on, including boom working lamp. Crane operation control – boom luffing, telescoping, slewing, hoisting, counterweight lifting. Cab side step telescoping – operator’s cab side step extending and retracting.
